Product Overview
The 30-Row 800 Single Sheet Roll Forming Machine is a high-efficiency cold bending equipment designed by [Your Brand Name] for manufacturing premium architectural roofing sheets. Specifically engineered to produce the classic 800-type glazed tiles (also known as imitation resin tiles), this single-layer machine features 30 precision forming stations. This advanced design ensures extremely smooth curves, high dimensional accuracy, and a scratch-free surface finish. It is the ideal industrial solution for producing color steel roof tiles widely used in residential villas, tourist resorts, and modern steel structure workshops.
Key Features & Advantages
-
30 Rolling Stations for Superior Forming Quality:
Unlike standard machines with fewer stations, our 30-row design allows for a gradual and smooth metal forming process. This effectively eliminates internal stress on the metal sheet, preventing edge buckling or deformation, and ensuring the final tile profile matches the mold perfectly with a high-quality glossy finish.
-
Heavy-Duty & Stable Machine Frame:
The main frame is constructed from thick H-beam steel plates, welded and stress-relieved for maximum rigidity. This heavy-duty structure ensures the machine runs smoothly at high speeds without vibration, significantly extending the lifespan of the rollers and bearings.
-
Advanced Hydraulic Cutting System:
Equipped with a post-cut hydraulic shearing system using high-grade Cr12Mov mold steel blades (heat-treated to HRC58-62°). The cutting action is smooth, burr-free, and maintains the structural integrity of the tile during the cut.
-
Intelligent PLC Control System:
Powered by a user-friendly PLC control system (Siemens/Delta/Mitsubishi optional) with a touch screen interface. Operators can easily set the production length, quantity, and speed. The system supports automatic counting, fault diagnosis, and precise length control (error within ±1mm).
-
Versatile Material Compatibility:
Suitable for processing Pre-painted Galvanized Steel (PPGI/Color Steel), Galvanized Iron (GI), and Aluminum coils.
- Material Thickness: 0.3mm – 0.8mm (Standard)
- Yield Strength: ≤ 230-350 Mpa
Technical Specifications
| Parameter |
Specification |
| Machine Name |
800 Single Sheet Glazed Tile Roll Forming Machine |
| Forming Stations |
30 Rows (High Precision) |
| Effective Width |
800mm |
| Main Motor Power |
7.5 kW - 11 kW (Frequency Control) |
| Hydraulic Power |
4 kW |
| Roller Material |
45# Steel with Hard Chrome Plating |
| Shaft Diameter |
70mm (Solid Steel) |
| Cutting Blade Material |
Cr12Mov with Heat Treatment |
| Working Speed |
8 - 12 meters/min (Adjustable) |
| Voltage |
380V/50Hz/3Phase (Customizable) |
| Control System |
PLC + Touch Screen + Encoder |
Application Areas
The 800 type single roof tiles produced by this machine are widely used for:
- Residential Villas, Private Houses, and Rural Housing Projects.
- Tourist Resorts, Landscape Architecture, and Ancient-style Buildings.
- Steel Structure Workshops and Warehouses requiring aesthetic roofing.
- Old Building Renovation and "Flat-to-Slope" Roof Projects.
Why Choose HeBei XinNuo?
- Factory Direct Supply: Competitive pricing with no middlemen, ensuring the best cost-performance ratio.
- Strict Quality Control: Every machine undergoes a 48-hour continuous running test and trial production before shipment.
- Global After-Sales Service: We provide comprehensive English installation manuals, operation videos, and 24/7 online technical support for overseas clients.
