Product Overview:
Engineered for modern large-span architectural projects, our Servo Tracking Shear Arc Roof Tile Roll Forming Machine is the ultimate solution for manufacturing high-strength, aesthetically pleasing curved metal roofing panels. Unlike traditional flat sheets, the arched profile produced by this curved metal sheet forming line offers superior wind resistance, enhanced structural stability, and excellent drainage capabilities. It is widely used in stadiums, industrial warehouses, and grand architectural domes.
Core Technology: Servo Tracking Flying Shear System
The standout feature of this equipment is its advanced Servo Tracking Shear System. Unlike conventional stop-and-cut methods, our machine utilizes a dynamic tracking mode where the main forming line runs continuously. The servo-driven cutter synchronizes perfectly with the moving steel sheet, achieving impressive cutting speeds of 25 to 40 meters per minute. This high-efficiency flying shear technology not only drastically reduces production cycles but also minimizes material waste, making it ideal for bulk manufacturing.
Precision & Durability:
To ensure millimeter-level accuracy, the machine adopts a single-side guide column shear structure. This robust design keeps the cutting tools on a highly precise trajectory, ensuring every tile meets strict arc and edge standards. Built with a heavy-duty welded steel frame, the equipment guarantees long-term stability and zero deformation under high-pressure forming conditions. The rollers are chrome-plated to prevent scratching the color-coated steel sheets, ensuring a flawless, mirror-like surface finish.
Intelligent Control & Easy Operation:
Controlled by a high-intelligence industrial PLC system with a touch screen interface, this automatic arc roof panel machine allows for seamless production management. Operators can easily set target lengths, monitor automatic counting, and perform quick mold changes. The system also features fault self-diagnosis, significantly lowering maintenance costs and technical requirements for operators.
Key Features & Benefits:
- High-Speed Production: Servo tracking shear enables non-stop cutting at speeds up to 40m/min.
- Millimeter-Level Precision: Single-side guide column structure ensures perfect cutting accuracy and consistent tile dimensions.
- Superior Finish Quality: Modular forming and chrome-plated rollers produce smooth, burr-free, and scratch-resistant curved panels.
- Robust & Stable: Heavy-duty frame and high-quality bearings ensure continuous, vibration-free operation.
- User-Friendly Interface: PLC touch screen control with automatic length setting and fault diagnosis.
Technical Specifications (Customizable):
| Forming Method |
Roll forming with modular pressure adjustment |
| Cutting System |
Servo Tracking Flying Shear (Non-stop cutting) |
| Cutting Speed |
25-40 meters/minute |
| Sheet Thickness |
0.3mm - 0.8mm (Galvanized / Color Coated Steel) |
| Control System |
Industrial PLC + Touch Screen |
| Application |
Large-span building roofs, industrial warehouses, architectural domes |
