Product Overview:
Our 3-Row Rubber Roller Slitting Machine Production Line is a state-of-the-art, fully integrated metal processing solution designed for high-precision strip manufacturing. Combining the superior tension control of a 3-row rubber roller system with versatile downstream processing capabilities, this line seamlessly handles Automatic Decoiling, Text Embossing, Hydraulic Punching, and Precision Bending. It is the ideal equipment for manufacturers producing specialized metal strips, lighting brackets, and structural components that require both accurate slitting and complex surface or structural modifications.
Key Production Processes & Technical Advantages:
- 1. Heavy-Duty Automatic Decoiling System:
The production line begins with a robust hydraulic decoiler, ensuring stable and smooth feeding of heavy metal coils. Equipped with an automatic loading cart and pinch rolls, it minimizes material scratches and reduces coil changeover downtime, setting the stage for high-speed continuous production.
- 2. High-Precision 3-Row Rubber Roller Slitting:
At the core of this machine is the advanced 3-row rubber roller slitting unit. The three rows of high-quality rubber rollers (typically 130mm diameter) provide exceptional material grip and tension distribution. This design ensures perfectly flat strip feeding, eliminates slippage, and guarantees burr-free, precise longitudinal shearing for materials like stainless steel, aluminum, and cold-rolled plates.
- 3. Custom Text Embossing & Hydraulic Punching:
Uniquely integrated into the line, the embossing unit can press custom text, logos, or anti-slip textures directly onto the metal strips. Following this, a high-tonnage hydraulic punching station accurately creates mounting holes or alignment slots. Both processes are synchronized with the slitting speed via an advanced encoder system, ensuring perfect pattern and hole alignment.
- 4. Precision Bending & Forming Station:
For applications requiring structural shaping, the line includes a precision bending/forming unit. It continuously bends the slit and punched metal strips into specific cross-sections (such as U-channels or lighting bracket profiles) with strict dimensional tolerance, eliminating the need for secondary processing.
- 5. Intelligent PLC Synchronization & Cutting:
The entire multi-process line is governed by a top-tier PLC control system (e.g., Siemens/Mitsubishi) and an HMI touch screen. Operators can easily set parameters for slitting width, embossing depth, punching patterns, and bending angles. The line concludes with a high-speed flying shear or hydraulic cutting system for clean, accurate final lengths.
Technical Specifications:
- Applicable Material: Stainless Steel, Aluminum Plate, Cold-rolled/Galvanized Plate
- Material Thickness: 0.5mm – 4.0mm (Customizable based on profile requirements)
- Slitting Width Accuracy: ±0.03mm
- Rubber Roller Configuration: 3-Row Rubber Rollers (High wear-resistant CR12 or specialized rubber)
- Forming & Slitting Speed: 0 – 150 m/min (Stepless speed regulation, adjustable based on punching/embossing complexity)
- Control System: PLC + HMI Touch Screen + Servo Motor Drive
- Power Supply: 380V/50Hz/3Phase (Customizable to client's local voltage)
Applications:
This versatile production line is extensively used in manufacturing:
- Precision metal strips for lighting brackets and photovoltaic mounting structures.
- Decorative metal strips requiring embossed logos or identification text.
- Structural components for the automotive, construction, and hardware industries.
- Custom-profiled metal strips requiring integrated punching and bending.
Why Partner With Us?
We specialize in designing non-standard, multi-functional roll forming and slitting solutions. From customizing the 3-row rubber roller specifications to designing unique embossing molds and bending dies based on your drawings, our engineering team ensures your production line maximizes efficiency and product quality. Contact us today to discuss your custom metal processing needs!
